Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards

China Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards supplier
Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards supplier Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards supplier

Large Image :  Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards

Product Details:

Place of Origin: Jiangsu, China
Brand Name: OLYMSPAN
Certification: ISO9001, ASME
Model Number: SN-CGF

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 5,000~50,000 set
Packaging Details: Shipping standard
Delivery Time: 45 days
Payment Terms: T/T
Supply Ability: 30 Sets Per Month
Detailed Product Description
Working Length: 1000~30000mm Working Pressure: 0.6~5Mpa
Temperature Uniformity: ±1.0~±3.0 Degrees Celsius Temperature Accuracy: ±1.0 Degrees Celsius
Pressure Accuracy: ±0.005Mpa Vacuum Pressure: ≤-0.098Mpa

Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards



Composite autoclave (series of SN-CGF)



In the last ten years, we have seen the evolution of new materials, with excellent mechnical and physical features. The mechanical resistance, together with the lightness of composite materials, are finding more and more applications. We call composite material the product obtained from the polymerization of carbon fibers and resins, adequately prepared and shaped overlapping coats of fibers abd resin on moulds or cores.

The autoclave is a key equipment for hot -pressing shaping of carbon fibres and resin matrix composites(polyimide,Bismaleimide,epoxy resin and thermoplastic resin metrices,etc.). In fact, the quality of the product is obtained inside the autoclave reaching an increase of mechanical features up to 20-30% compared to other methods of polymerisation, which do not foresee the outside pressurisation of the product.



The reliability and the precision of the cycles which can be obtained with Olymspan autoclave,allow to reach and keep high quality standards of the product ,which is widely used in the high-tech fields such as aerospace, automotive,electronics,weapon,traffic,sports equipment and new type of energy,etc.

Pneumatic Glass Laminating Autoclave Glass Reactor With TPC Control System Of GB150 Standards



Technical specification

Item design parameter
working diameter 600~6000mm
working length 1000~30000mm
working temperature 100~400 degrees celsius
working pressure 0.6~5Mpa
temeprature unformity ±1.0~±3.0 degrees celsius
temperature accuracy ±1.0 degrees celsius
pressure accuracy ±0.005Mpa
vacuum pressure ≤-0.098Mpa




Features:

Advanced Thermal Process Control System (TPC) based on PC platform,with a reliable and powerful performance;



Unique heating system on the bottom and cooling system, to save the running cost;



The design of screen type air duct can balance and force the convection airflow to get a perfect temperature uniformity in the autoclave;



Fully sealed direct connect special motor, to prevent air and oil leakage;



Parts and materials of high qualityl



Various of manufacturing standard.GB150/ASME/PED/AD;



Customize specification;
