Wood Autoclave With Safety Interlock , Automatic Control High Temperature And High Pressure

Wood Autoclave With Safety Interlock , Automatic Control High Temperature And High Pressure

automatic autoclave

autoclave pressure vessel

Place of Origin:


Brand Name:




Model Number:


Contact Us
Request A Quote
Product Details
Place Of Origin:
1 Year
45 Working Days
Heating Power:
Inner Diameter:
Effective Length:
High Light:

automatic autoclave


autoclave pressure vessel

Payment & Shipping Terms
Minimum Order Quantity
USD 5,000~5,000,000 set
Packaging Details
Delivery Time
45 days
Payment Terms
Supply Ability
10 Sets Per Month
Product Description

Wood Autoclave With Safety Interlock , Automatic Control High Temperature And High Pressure



Quick Details:

Medium: compressed air
Type: Wood Autoclave
Inner diameter: 1.65m, 2m, 2.5m, 2.68m, 2.85m
Applications: Wood, Brick, Rubber, Food, Glass industry and so on


Medium of our autoclave is compressed air. Usual specification we manufacture includes 1.65m,2m,2.68m,2.85m. Besides, we could meet different customers' different requirements.


Our composite autoclave could meet different industries' needs. For example, it could service wood industry, block brick industry,rubber industry,food industry,glass industry,textile industry and so on.






AAC Autoclave

Wood autoclave

Rubber vulcanizing autoclave

Glass autoclave

Composite materials autoclave


We namufacture different kinds of composite autoclaves include aac autoclave, wood autoclave, rubber vulcanization autoclave and glass autoclave and other composite autoclaves.



1. Wood industry
2. Brick industry
3. Rubber industry
4. Food industry
5. Glass industry


Wood autoclave is a kind of key equipment, which is used for wood deep-processing. To achieve the safety demands of laminated Wood through the pressure and heat treatment process.
It is widely used in automotive industry, aerospace, defense industry, building decoration, etc. It is equipped with the safety valve, the pressure gauge, the temperature element and so on.

Besides power driven, pneumatic ways to open the door, it also has the safety interlock. There are heating elements for warming & forcing and cooling device inside of the autoclave. It will automatic control and detect the opening and closing doors, temperature, pressure in autoclave by PLC controller, which is the wood workpiece precess.


Items Unit Specifications and Parameters
FJK1.4-1.65×4D FJK1.5-2×5D FJK1.5-2.5×5D FJK1.5-2.68×5D FJK1.5-2.85×5D
Inside diameter M 1.65 2 2.5 2.68 2.85
Effective length M 4 5 5 5 5
Design pressure Mpa 1.4 1.5 1.5 1.5 1.5
Design temperature °C 150 150 150 150 150
Working pressure Mpa 1.3 1.4 1.4 1.4 1.4
Working temperature °C 150 150 150 150 150
Medium   air air air air air
Gauge MM 900 1000 1000 1000 1000
Effective volume M3 10 18 25 28 31
Gross weight T 7 9 16 25 30
Overall dimension M 6×2.5×3 7×2.8×3 7×3×3.5 7.8×3.2×3.8 9×3.5×5


Feartures of wood impregnation plant


1) Wood treatment equipment apply to be preservation ,termite proof ,and to prevent fungal .Especially outdoor wood floor ,landscape floor ,outdoor wood platform ,and wood plank road ,and other preservative wood pergola .


2) This treatment equipment have special craft for wood ,such as :vacuum pressure method ,fullcell method ,high low frequency pressure as so on . Especially vacuum pressure method ,The preservative level can get C4.

3) You can use CCA and ACQ two kinds of preservative match our wood preservation equipment.


4) PLC is a new intelligent control wood preservative system ,which make the wood preservationequipment to be easy ,and to be safety ,to be reliable .Meanwhile ,Even if the wood don't be push out ,this can accurately calculate if the preservative is permeated in the wood .


Our company:

Wood Autoclave With Safety Interlock , Automatic Control High Temperature And High Pressure 0


For much more detailed information, contact us for business discussion.


Welcome to pay a visit to our factory!
