AAC Autoclave with swing device and hand reducer

China AAC Autoclave with swing device and hand reducer supplier
AAC Autoclave with swing device and hand reducer supplier AAC Autoclave with swing device and hand reducer supplier

Large Image :  AAC Autoclave with swing device and hand reducer

Product Details:

Place of Origin: China
Brand Name: OLYMSPAN
Certification: CE, ASME
Model Number: FGZSS

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 5,000~5,000,000 set
Packaging Details: Shipping standard
Delivery Time: 1 Month
Payment Terms: T/T,L/C
Supply Ability: 30 Sets Per Month
Contact Now
Detailed Product Description
Working Temperature: 201 ℃ Working Pressure: Mpa
Medium: Saturated Steam And Condensed Water Door Opening: Manual,hydraulic-pressure,elelctrical,pneumatic
Shell Thickness: 16mm

Food Rubber AAC Autoclave Pressure Vessel For Chemical / Textile / Wood



Quick Details



Type: AAC Autoclave

size : Φ2.68 * 38m

Automatic: Yes

Brick Raw Material: Fly ash, Sand, Cement, Gypsum, Lime and etc

application: wood, rubber, composite materials, aerospace, textile.

design pressure: 1.6Mpa

working pressure:1.5Mpa



design temperature:204

working temperature: 201



Description:



AAC autoclave is a kind of Class I or Class II pressure vessel.



We have strict standards for materials of pressure parts. For lid, we use 16MnR, and for plate, we use GB6654 plate.



Autoclave belongs to pressure vessel which has explosion risk. According to the supervision regulation on safety technology for pressure vessel on divide standard of pressure vessel, the product is part of first and second class pressure vessel.



This product is key equipment which has a widely application in building material factory to autoclaved cure different kinds of building materials. It is also used in areas of chemical, textile, wood, metallurgy, military industry. Convenient operation, security and reliable are its advantages.




Specifications:





Item

Type

FGZSS

1.5-1.65*L

FGZCS

1.5-2*L

FGZSS

1.5-2.5*L

FGZSS

1.5-2.68*L

FGZSS

1.5-2.85*L

FGZCS

1.5-3*L

FGZCS

1.5-3.2*L

Inner diameter

Ø 1.6m

Ø 2m

Ø 2.5m

Ø 2.68m

Ø 2.85m

Ø 3m

Ø 3.2m

Length

L

L

L

L

L

L

L

Designed pressure

1.6Mpa

1.6Mpa

1.6Mpa

1.6Mpa

1.6Mpa

1.6Mpa

1.6Mpa

Designed temperature



204℃



204℃



204℃



204℃



204℃



204℃



204℃

Max operation pressure

1.5Mpa

1.5Mpa

1.5Mpa

1.5Mpa

1.5Mpa

1.5Mpa

1.5Mpa

Max operation temperature

201℃

201℃

201℃

201℃

201℃

201℃

201℃

Medium

Saturated steam

Track gauge/height

600mm/

150mm

600mm/

150mm

800mm/

200mm

800mm/

250mm

963mm/

280mm

1220mm/320mm

1220mm/

320mm

Corrosion allowance

2mm

2mm

2mm

2mm

2mm

2mm

2mm





Applications:



1. Glass industry

2. Brick industry

3. Rubber industry

4. Food industry

5. Wood industry
6. aerospace industry

7. textile industry

8. composite materials


Competitive Advantage:



Autoclave is a kind of large-scale steam equipment. It can be used to steam sand lime brick, flyash brick, slag brick, aerated concrete block, cement pile and other cement products. Besides that, it also has a widely application in deep processing of glass, wood, rubber, thermal insulation material, medicine, high strength gypsum, sizing the fishing net industry and so on. We can manufacture various forms of the autoclaves according to the requirements of our customers.



Experts In our company absorbed the advantages of foreign similar products, and improved the strength calculation by analyzing the main pressure parts and doing all kind of stress test.





AAC Autoclave with swing device and hand reducerAAC Autoclave with swing device and hand reducer

Our Team:

AAC Autoclave with swing device and hand reducerAAC Autoclave with swing device and hand reducer

AAC Autoclave with swing device and hand reducerAAC Autoclave with swing device and hand reducer

AAC Autoclave with swing device and hand reducerAAC Autoclave with swing device and hand reducer
