2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation

China 2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation supplier
2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation supplier 2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation supplier 2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation supplier

Large Image :  2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation

Product Details:

Place of Origin: China
Brand Name: OLYMSPAN
Certification: ISO, ASME
Model Number: MCF

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: USD 5,000~5,000,000 set
Packaging Details: Nude
Delivery Time: 45 days
Payment Terms: T/T
Supply Ability: 10 Sets Per Month
Contact Now
Detailed Product Description
Installation: Overseas Guiding Commissioning: Overseas Guiding
After-sale Service: Engineers Overseas To Service Working Temperature: 150 ℃
Working Pressure: 1.3Mpa

2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation​





Application:

1. Rubber products: hose, roller, shoes, etc.

2. Textile industry: printing and dyeing

3. Wood treatment for impregnation





Quick Details:
Medium: compressed air
Type: Wood Autoclave
Inner diameter: 1.65m, 2m, 2.5m, 2.68m, 2.85m
Applications: Wood, Brick, Rubber, Food, Glass industry and so on



Categories:



AAC Autoclave

Wood autoclave

Rubber vulcanizing autoclave

Glass autoclave

Composite materials autoclave





1. Brief Introduction of wood impregnation plant



Industrial autoclaves (also known as still kettle) are pressure vessels used to process parts and materials, which require exposure to elevated pressure and temperature. The manufacture of high-performance components from advanced composites often requires autoclave processing



2. The working flowchart of wood impregnation plant :



full-cell process method to make preservative wood can be divided into the following stages:

close the tankdoor————turn on the air compressor-- start initial vacuum after the air compressor stop automatically————add pressure————discharge the liquid————final vacuum-- turn off the air compressor————restoreair————discharge the rest liquid-————open the pressure tank door.





Specifications:

Items Unit Specifications and Parameters
FJK1.4-1.65×4D FJK1.5-2×5D FJK1.5-2.5×5D FJK1.5-2.68×5D FJK1.5-2.85×5D
Inside diameter M 1.65 2 2.5 2.68 2.85
Effective length M 4 5 5 5 5
Design pressure Mpa 1.4 1.5 1.5 1.5 1.5
Design temperature °C 150 150 150 150 150
Working pressure Mpa 1.3 1.4 1.4 1.4 1.4
Working temperature °C 150 150 150 150 150
Medium   air air air air air
Gauge MM 900 1000 1000 1000 1000
Effective volume M3 10 18 25 28 31
Gross weight T 7 9 16 25 30
Overall dimension M 6×2.5×3 7×2.8×3 7×3×3.5 7.8×3.2×3.8 9×3.5×5



Technology details:

1. Door: manual quick open/close system

2. Electric-heating boiler to generate steam, there's no environmental pollution.

3.triple safety interlocks to ensure safety during process.

4. Insulation layer: rock wool ensures heat saving.

5. Full-automatic or semi-automatic control, adopt PLC control system.







Our company:

2.0X12M High Pressure Autoclave Wood Dipping Treatment Reactor With Siemens PLC Control Panel For Wood Impregnation



For much more detailed information, contact us for business discussion.



Welcome to pay a visit to our factory!
